| 书目名称 | PSpice for Filters and Transmission Lines | | 编辑 | Paul Tobin | | 视频video | | | 丛书名称 | Synthesis Lectures on Digital Circuits & Systems | | 图书封面 |  | | 描述 | In this book, PSpice for Filters and Transmission Lines, we examine a range of active and passive filters where each design is simulated using the latest Cadence Orcad V10.5 PSpice capture software. These filters cannot match the very high order digital signal processing (DSP) filters considered in PSpice for Digital Signal Processing, but nevertheless these filters have many uses. The active filters considered were designed using Butterworth and Chebychev approximation loss functions rather than using the ‘cookbook approach’ so that the final design will meet a given specification in an exacting manner. Switched-capacitor filter circuits are examined and here we see how useful PSpice/Probe is in demonstrating how these filters, filter, as it were. Two-port networks are discussed as an introduction to transmission lines and, using a series of problems, we demonstrate quarter-wave and single-stub matching. The concept of time domain reflectrometry as a fault location tool on transmission lines is then examined. In the last chapter we discuss the technique of importing and exporting speech signals into a PSpice schematic using a tailored-made program Wav2ascii. This is a novel techni | | 出版日期 | Book 2007 | | 版次 | 1 | | doi | https://doi.org/10.1007/978-3-031-79764-4 | | isbn_softcover | 978-3-031-79763-7 | | isbn_ebook | 978-3-031-79764-4Series ISSN 1932-3166 Series E-ISSN 1932-3174 | | issn_series | 1932-3166 | | copyright | Springer Nature Switzerland AG 2007 |
The information of publication is updating
|
|
发表于 2025-3-21 18:37:10
