| 书目名称 | Design of Low-Voltage Bipolar Operational Amplifiers |
| 编辑 | M. Jeroen Fonderie,Johan H. Huijsing |
| 视频video | |
| 丛书名称 | The Springer International Series in Engineering and Computer Science |
| 图书封面 |  |
| 描述 | .DesignofLow-VoltageBipolarOperational Amplifiers.discusses the sub-circuitsnecessaryto build a low-voltageoperational amplifier. Theseincluderail-to-rail input stages,rail-to-rail output stages, intermediatestages,protectioncircuitry and frequency compensation techniques.Ofeachof these,various implementations are examined. Furthermore,thebookdiscussesrealizationsinsiliconofthe amplifiers..Thedesignandimplementationoflow-voltagebipolar OperationalAmplifiers (OpAmps)isfullypresented.Alowsupply voltage isnecessarybecausethetendencytowardschip components of smallerdimensionslowers the breakdown voltage of these components. Further,alow supply voltage is favorable because it enables operation of theOpAmpfromjustonesingle battery cell. The bipolar technology ischosen,becauseit is more suited for operation at low-voltages thanthe MOS technology..Thecommon-modeinputvoltage of the OpAmp must be able to have anyvaluethatfitswithinthesupply voltage range. Input stages arediscussedwhichareable to realize this at supply voltages down to1.8 V, as well as down to 1 V..Theoutput voltage of the OpAmp must be able to have any value withinthesupplyvoltagerange.Oneofthe1V output stages that isdiscuss |
| 出版日期 | Book 1993 |
| 关键词 | Limiter; Volt; bandwidth; circuit; design |
| 版次 | 1 |
| doi | https://doi.org/10.1007/978-1-4615-3142-5 |
| isbn_softcover | 978-1-4613-6375-0 |
| isbn_ebook | 978-1-4615-3142-5Series ISSN 0893-3405 |
| issn_series | 0893-3405 |
| copyright | Springer Science+Business Media New York 1993 |
