| 书目名称 | Heterostructures on Silicon: One Step Further with Silicon |
| 编辑 | Yves I. Nissim,Emmanuel Rosencher |
| 视频video | |
| 丛书名称 | NATO Science Series E: |
| 图书封面 |  |
| 描述 | In the field of logic circuits in microelectronics, the leadership of silicon is now strongly established due to the achievement of its technology. Near unity yield of one million transistor chips on very large wafers (6 inches today, 8 inches tomorrow) are currently accomplished in industry. The superiority of silicon over other material can be summarized as follow: - The Si/Si0 interface is the most perfect passivating interface ever 2 obtained (less than 10" e y-I cm2 interface state density) - Silicon has a large thermal conductivity so that large crystals can be pulled. - Silicon is a hard material so that large wafers can be handled safely. - Silicon is thermally stable up to 1100°C so that numerous metallurgical operations (oxydation, diffusion, annealing ... ) can be achieved safely. - There is profusion of silicon on earth so that the base silicon wafer is cheap. Unfortunatly, there are fundamental limits that cannot be overcome in silicon due to material properties: laser action, infra-red detection, high mobility for instance. The development of new technologies of deposition and growth has opened new possibilities for silicon based structures. The well known properties |
| 出版日期 | Book 1989 |
| 关键词 | Epitaxy; RHEED; Vakuuminjektionsverfahren; metal; optical properties; quantum wells; semiconductor; silicon |
| 版次 | 1 |
| doi | https://doi.org/10.1007/978-94-009-0913-7 |
| isbn_softcover | 978-94-010-6900-7 |
| isbn_ebook | 978-94-009-0913-7Series ISSN 0168-132X |
| issn_series | 0168-132X |
| copyright | Kluwer Academic Publishers 1989 |
